High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

    • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm
    • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm
    • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm
    • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm
    • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm
  • High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: jiayuan
    Certification: CE,ISO,SGS
    Model Number: RCGF32-32-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Price: US $15,000 - 800,000 / Set
    Packaging Details: wooden box
    Delivery Time: 30 work days
    Supply Ability: 10 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Packaging Material: Paper, Plastic, Wood Packaging Type: Barrel, Bottles, Cans
    Voltage: 380V 50Hz Driven Type: Electric
    Automatic Grade: Automatic Warranty: One Year
    Material: Food Grade Stainless Steel 304 Control System: PLC Control
    Filling Type: Normal Pressure Filling After-sales Service Provided: Engineers Available To Service Overseas

    3600*2800*3150mm High pressure processing juice filling machine top quality



    Specifications:

    3600*2800*3150mm High pressure processing juice filling machine top quality

    1. CE,ISO certificate
    2. PLC control
    3. Juice bottling equipment, hot juice filling



    1) Feature

    a. The juice filling machine is used to fill PET heat-resistant bottle for fruit tea, juice and other high-temperature juice.

    b. The core parts of machine employs PLC+, frequency convertor+ and human-machine interface control technology

    c. The machine can be connected with UHT, CIP control center and bottle-invert sterilizer

    d. The machine structure is reasonable and firm, the running state is stable

    e. The suspension bottle neck catcher allows the machine change the bottle type easily

    f. Safe protective devices ensure safety of operator and machine

    g. Magnetic torsion type screw capper ensures the tightness of the cap and avoids bottle damage

    h. The module of screw capper ensures the tightness of the cap and avoids bottle damage

    i. Slight negative-pressure gravity circumfluence filling system increases juice filling accuracy and reduces contamination

    j. Unique control mechanism keeps circumfluence volume below 5%

    k.Airtight valve made of non-plastic material prevents worn-out particles from dropping into bottles adversely affecting product quality

    2) Technique parameter

      RCGF16-12-6 RCGF24-24-8 RCGF32-32-10
    Productivity 3000BPH 10000BPH 14000BPH
    Rinsing Head 16 24 32
    Filling Head 12 24 32
    Capping Head 6 8 10
    Bottle Volume 350ml~2000ml±10ml
    Bottle Diameter φ50-92mm
    Bottle Height 150-310 mm
    Filling Tolerance ±2%
    Cap Size 28mm and 30mm PE Standard Caps
    Air Pressure 0.6MPa
    Air Consumption 500 L/min
    Gas Consumption 0.3 m3/min 0.4 m3/min 0.5 m3/min
    Motor Power 5.88kW 7.68kW 9.18kw
    Voltage 380V
    Dimension (L×W×H) 2100*1500*2200mm (L×W×H) 2750*2180*2200mm (L×W×H) 3600*2800*3150mm
    Weight 2500kg 5300kg 5000kg
    Filling Principle Gravity Filling

    High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

    High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

    High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm



    Our service

    1.One year warranty for the whole system.

    2.Free equipment installation and debugging.

    3.After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

    4.We can provide internship service and help you train the operator and mechanic.

    5.Free beverage production technology and process configuration.

    6.We can help you to design the product line, workshop and provide turn-key project.



    Advantages

    We offer professional turnkey project from design till done of the whole project.

    1.Project consultation

    2.Design

    3.Factory building

    4.Installation

    5.Commissioning

    6.Training



    We can provide beverage filling line as below:

    1. Complete pure/mineral water production line

    2. Complete pure/mineral water treatment machine

    3. Complete juice production line

    4. Complete carbonated beverage production line

    5. 5 Gallons drinking water production line.

    6.End-of-line packaging system



    Packing and shipping

    High Pressure Processing Juice Water Bottling Machine 3600 * 2800 * 3150mm

    FAQ

    Q : How to get your suitable machine or production line?

    A : Find our products through zhangjiagang Jiayuan machinery co ., ltd . in google, bing, yahoo, alibaba . com ect .

    Enquiry : Contact us by email , phone call , fax , instant messenger (trade manager , MSN , skype , whats app) and let us know your enquiry.

    Disscussion : Specify the items you desire , confirm specification ; OEM/ODM consultation .

    Q : What is the type of your company?

    A : We are the professinal beverage machinery manufacturers to produce bottled liquids,drums,filling machine,installed cup carbonated drinks,such as filling machine. We not only sell machiners, but also sell our brand and service .

    Q : Do you have technical support after we purchased your machines?

    A : Definitely ! We will arrange our professional engineers to go aboard to your factory (company limited) , they will teach you how to install and maintenance the machines which you purchased . or help you to fix machine when it has problems .

    Q : If you buy our machines , can you offer us wear-out spare parts?

    A : No problem ! We will offer you 1 year free wear - out spare parts . As well as 1 year warranty . Once your machines broken or doesn't work within 1 year and you can't solve it . Firstly , we will try to help you to find problems from your words description by phone or other communication tolls . Secondly , if the phone solutions still not work , our engineers will go to your factory (company limited) to solve it . Meanwhile they will teach you the related experiences for fixing .



    Company Information

    Jiayuan company was established in 1997, We are a company integrating scientific research, production and service, and have the best manufacturing facilities and production process, professional staffs, imported facilities of concentration distill series, automatic CIP series, PLC control etc. Now we have been a market leader in the Chinese food machinery industry. The company keeps in mind the tenet of "serving users" and focus on research and development of new technologies. It has comprehensive development capacity and sound quality assurance system, and has made R&D achievement and obtained invention patents. Our machinery are widely sold in China, and exported over 20 countries, and gained favorable feedback from users. Our major engineering projects include complete dairy products production line, beverage production line, biochemical engineering production line.
