3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage

3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage

    • 3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage
    • 3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage
    • 3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage
    • 3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage
  • 3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage

    Product Details:

    Place of Origin: CHINA,MAINLAND
    Brand Name: JIAYUAN
    Certification: CE,SGS
    Model Number: RCGF

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 5000-64000 set
    Packaging Details: wooden
    Delivery Time: 30 work days
    Payment Terms: T/T
    Supply Ability: 15 sets per month
    Contact Now
    Detailed Product Description
    Material: Sus 304 Voltage: Customized
    Packing Material: Wooden Cases Control: Touch Screen
    Warranty: 1year Driven Type: Electric
    Filling Volume: Adjustable Service: Engineer Overser



    CE SGS 3000kg fruit juice machine making machine with engineer oversea service



    Introduction:
    This drinking water filling equipment adopts bottle neck holding transmission technology to realize fully automatic sterilizing, rinsing, filling, and capping. Most elements of the electrical system employ foreign advanced products. Each machine element that contacts with the liquid is made of high quality stainless steel. They obtain the advantages of good abrasive resistance, high stability, low failure rate,etc. The quality of the equipment reaches the international advanced level.

    3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage




     Rinser
    1.Rotative rinsing turret one treatment, fixed nozzles, with grippers.
    2.The grippers take the bottles from the inlet starwheel while they are still driven by the starwheel, thus guaranteeing a safe grip.
    -After the gripping, the bottle is turned upside down and centred above a spraying nozzle which directs a stream of rinse water into the bottle. After the draining period the bottle is turned over to an upright position again.

    3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage
    Filler
    1.The starwheels drive the bottles always "by the neck" through the rinsing, filling and capping steps. For the various types of bottle, it is easy to adjust the structure for the operator by our specialized design.
    2. Product bowl is to reduce the loss of heat.
    3.If the temperature is low than the setting value, the filling valves will stop and return the last beverage in filling valve to recycle tank and return to UHT again to sterilize with pump.

    3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage

    Capper
    1. Rotative capping turrent, suitable to the application of screw plastic caps on PET bottles
    2.The fixed part consists of the cap hopper, the cap feeder with relevant motor and the cam actuating the capping heads.
    3.The heads are raised and lowered by the action of a follower that is riding on a shaped cam.


     3000 Kg Fruit Juice Filling Machine / Making Machine With Customized Voltage


    Model RCGF24-24-8 RCGF32-32-10 RCGF40-40-12
    Production Capability(b/h)(500ml) 10000 14000 15000-20000
    Applicable Bottle Type Bottle DiameterØ50- Ø92mm; Height150-310mm; Volume330-1500ml
    Applicable Cap Shape Plastic Screw Cap
    Gas Source Pressure(Mpa) 0.6
    Gas Consumption(m³/min) 0.4 0.4 0.5
    Total Power(kw) 7.68 9.18 9.18
    Total Weight(kg) 4000 5000 5000
    Dimension(L×W×H)(mm) 2750*2180*2200 3600*2800*3150 3600*2800*3150




    Service



    1.Installation

    After equipments reached the workshop of customer, place the equipments according to plane layout we offered. We will arrange seasoned technician for equipments installation, debug and test production at the same time make the equipments reach the rated producing capacity of the line. Time for installation and debug is 15-25 days.

    2.Training

    Our company offer technology training to customer. The content of training is structure and maintenance of equipments, control and operation of equipments. Training is in the workshop of customer. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

    3.Quality Guarantee

    We promise that our goods are all new and not used. They’re made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.

    4.Aftersales

    1,After checking, we offer 12 months as quality guarantee, free offer wearing parts and offer other parts at the lowest price. In quality guarantee, the technician of buyers should operate and maintain the equipments according to seller’s demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.



    2,After quality guarantee, we offer technology support and after sales service. Offer wearing parts and other spare parts at favorable price; after quality guarantee, the technician of buyers should operate and maintain the equipments according to seller’s demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.
