Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise

Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise

    • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
    • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
    • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
    • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
    • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
  • Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: Jiayuan
    Certification: CE SGS ISO
    Model Number: CGF16-16-5

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Price: US $15,000 - 800,000 / Set
    Packaging Details: wooden box
    Delivery Time: 30 work days
    Supply Ability: 10 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Application: Beverage, Chemical, Food Packaging Material: Paper, Plastic, Wood
    Automatic Grade: Automatic Voltage: 380V 50Hz
    Control System: PLC Control Material: SS304/316
    Capacity: 3000BPH Bottle Volume: 5L

    Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise


    Video show https://www.youtube.com/watch?v=Lr1YHsi1D5A&feature=share


    Quick information:

    1. This machine is used for filling 5L plastic/pet bottle

    2. Capacity:3000 bottles per hour

    3. washing filling capping 3-in-1 monoblock machine



    Features

    1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.

    2. Bottles transmission adopt clip bottleneck technology, anna com bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.

    3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.

    4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.

    5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.

    6. Super-low star wheel structure can highly improve the strength of the whole machine.

    7. Central greasing oil system can grease all bearings easily.

    8. Gearbox type capping unit gives a close structure, keep oil inside also using Egers material for longlife. You can also adjust the capping rounds according to different caps by adjusting gears below.

    9. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON,ABB.



    Technical parameter

    Model CGF16-16-5 CGF18-18-6 CGF24-24-8 CGF32-32-10
    Production capacity(500ml)(b/h) 4000 4000-6000 8000-10000 12000-15000(0.5L)
    Filling precision ≤±5MM(Liquid Level)
    Polyester bottle standard(mm) Bottle diameter:Φ40-Φ80;Height:130-280



    Bottle diameter:Φ50-Φ100;Height:150-320



    Suitable cap shape Plastic Screw Cap
    Water pressure of Washing bottle(MPa)

    0.18



    Water consumption for Water bottle 800kg/h 1600kg/h 2500kg/h 3500kg/h
    Spraying position 5 5 6 12
    Dripping bottle position 3 3 3.5 7
    Gas source pressure(Mpa) normal pressure
    Gas consumption(m3/mm) 0.3 0.3 0.4 0.5
    Total power(kw) 4.23 5.03 6.57 8.63
    Total weight(kg) 2000 3500 5500 8000
    Dimension(L*W*H) 2100×1500×2200 2450×1800×2200 2750×2180×2200 3500×2200×2250



    Pictures show

    Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise



    Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise



    Automatic Pure Water Filling Machine / PET Bottling Equipment Low Noise
