Zhangjiagang Jiayuan Machinery CO., LTD
Professional liquid beverage filling and packing machinery manufacturer
Place of Origin: | Jiangsu, China (Mainland) |
Brand Name: | Jiayuan |
Certification: | CE SGS |
Model Number: | QJ |
Minimum Order Quantity: | 1 Set/Sets (Min. Order) |
---|---|
Price: | US $4,100 - 4,700 / Set |
Packaging Details: | wooden package |
Delivery Time: | Shipped in 10 days after payment |
Supply Ability: | 15 Set/Sets per Month |
Blow Moulding Type: | Stretch Blow Moulding | Automatic: | Semi-auto |
---|---|---|---|
Plastic Processed: | PE PET PP | Valve: | TPC |
Machine Type: | Injection Blow | Cylinder: | FESTO |
High Light: | blow moulding machine,Bottle Molding Machine |
Semi Auto Bottle Blowing Machine PET PP PE plastic injection machine 0.1 - 3L 2 Cavity
1. Machine description
Blow molding machine is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
---Perfect function with economic investment.
---Small size and compact construction with no space waste.
---Easy to operate and maintain ,operation by one person .
---Saving power and uneasy to worn out ,Adopting new double crank four bars to lock mould, the cross fixed. Providing high pressure blowing system.
---We can provide performs and various bottle& cap molds for 5 gallon and 3gallon bottles to meet customer’s requirements.
Semi-auto blow moulding machine for PET bottle has been improved and designed by CE standard. With microcomputer controlling system, it controls various technical parameter needed more accurately and more steadily. Only one person without special training operates it more easily and more safely.
Semi-auto blow moulding machine is fit to blow carbonated beverage bottles, mineral water bottles, cosmetics bottles and hot-filling bottles.
Features
1. Produce bottle from 0.1L to 3L
2. Output capacity up to 900 for 0.6L using two-cavity blow mold
3. Advanced PLC control system with a use-friendly panel and time-control precision of PLC up to 0.01second
4. Equipped with special designed air storage unit
5. Using Infrared preform heater
6. Independent Temperature Control for different heating lamp to get ideal preform heating results
7. Heating lamps are adjustable in directions to suit various preforms.
8. Operated only by one person without special training.
9. Simple installation & startup adjustment.
10. Waste rate of finished bottle is less than 0.2%.
Design Ability | All the machines designed by CAD |
Manufacturing Ability | Mechanical parts: high quality stainless steel, processed by CNC |
Reliability | Electrical parts from world famous suppliers |
Professional |
Focus on beverage and cosmetics packing machines Exported to over 20 countries with good reputation 6 years Alibaba Golden supplier without complaint |
Good Service: | Service include complete production line design, manufacturing, on-site installation & aftersales maintenance. |
Profession on Export: | Authorized export licence. |
Technical parameter:
Model | ITEM | ||
Container | Product material | / | PET |
Volume | L | 10-25(3-5gallon) | |
Theoretical output | pcs/h | 90-180 | |
Preform length | mm | ≤500 | |
Preform inner diameter | mm | φ15-200 | |
Mould | Max. mould plate Diameter(L*W) | mm | 420*500 |
Max. mould thickness | mm | 400 | |
Mould opening stroke | mm | 380 | |
Machine size and Weight | Main machine (L*W*H) | cm | 2180*770*1960 |
Main machine weight | kg | 1000 | |
Heater (L* W*H) | cm | 2370*680*1650 | |
Heater weight | kg | 318 | |
Power | kw |
40 |
Pls contact me and let's talk more details, thanks in advance!
Zhangjiagang Jiayuan Machinery Co., Ltd
Tel:+86-15962351473
wechat:15962351473
skype:Joyce1989280
whatsAPP:+8615962351473
Factory Add:
No.198,Zhenbei Road,Leyu Town, Zhangjiagnag City , JiangSu Province .PRC
POST CODE :215625
