Commercial Fruit Juice Hot Filling Machine / Making Machine SGS Certification

Commercial Fruit Juice Hot Filling Machine / Making Machine SGS Certification

Commercial Fruit Juice Hot Filling Machine / Making Machine SGS Certification

Product Details:

Place of Origin: Jiangsu, China (Mainland)
Brand Name: jiayuan
Certification: CE,ISO,SGS
Model Number: RCGF18-18-6

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set/Sets
Price: US $15,000 - 800,000 / Set |
Packaging Details: wooden box
Delivery Time: 30 work days
Supply Ability: 10 Set/Sets per Month
Contact Now
Detailed Product Description
Type: Filling Machine Application: Beverage, Chemical, Food
Packaging Material: Paper, Plastic, Wood Automatic Grade: Auto
Dimension(L*W*H): 2450*1800*2200mm Weight: 3000kg
Material: Food Grade SS304 Warranty: One Year
Control System: PLC Control Filling Temperature: Room Temperature
High Light:

Liquid Filling Machine

,

automatic filling machine

Hot selling commercial fruit juice making machine/tea filling machine



Specifications

Hot selling commercial fruit juice making machine/tea filling machine

1.Juice making machine, tea filling machine

2.CE,ISO,SGS

3.hot filling machine



Hot selling commercial fruit juice making machine/tea filling machine

This hot filling equipment adopts bottle neck holding transmission technology to realize fully automaic rinsing,filling and capping.It is equipped with perfect temperature control system,reverse-flow system,automatic cleaning system and control program.Each machine element that contacts with the liquid is made of high quality stainless steel and food-grade rubber.



1) Feature

Hot selling commercial fruit juice making machine/tea filling machine

Standard 3-in-1 monoblock for PET bottles rinsing, hot filling and capping. It is applicable to fruit juice, tea beverage, functional beverage, etc with 2000-20000BPH capacity. According to the special production condition, another sterilizing rinsing module could be added, that is 4-in-1 monoblock. The system has fully considered the beverage's characteristics (such as the frothing of the tea drink and mixed juice) and the technical requirement of the hot filling.
1.Full filling to avoid the bottle from sinking after the bottle cooling off, and to decrease the dissolved oxygen to the utmost extent.
2.Reasonable structured storage hopper and material supply system make the material in constant flow speed, constant pressure without frothing. Usually high position tank is adopted.
3.The storage hopper has the characteristic of gas discharge, full sealing and temperature detecting. In moderate and high speed production line, the material distributor replaces the big liquid tank to realize the complete CIP.
4.Sanitary filling head system is of umbrella structure, high filling speed.
5.Perfect filling temperature control system.
6.Reflux tank system has the function of supplying the material automatically.
7.Perfect CIP system.


2) Technique parameter

  RCGF16-12-6 RCGF18-18-6 RCGF24-24-8
Productivity 3000BPH 6000BPH 10000BPH
Rinsing Head 16 18 24
Filling Head 12 18 24
Capping Head 6 6 8
Bottle Volume 350ml~2000ml±10ml
Bottle Diameter φ50-92mm
Bottle Height 150-310 mm
Filling Tolerance ±2%
Cap Size 28mm and 30mm PE Standard Caps
Air Pressure 0.6MPa
Air Consumption 500 L/min
Filling Water Consumption 1.5 m3/h 3 m3/h 6 m3/h
Rinsing Water Consumption 0.5 m3/h 1 m3/h 2 m3/h
Motor Power 5.88kW 6.68kW 7.68kW
Voltage 380V
Dimension

(L*W*H)

2100*1500*2200mm

(L×W×H) 2450*1800*2200mm (L×W×H) 2750*2180*2200mm
Weight 2500kg 3000kg 5300kg
Filling Principle Gravity Filling

Kindly remind
Please kindly send us your requirements:
1, bottle vlolume
2, bottle materail (machines for glass bottle and plastic bottle are different)
3, how many bottlesper hour you want to produce ?
4, do you need this water filling machines only or whole water production line

Advantages

We offer professional turnkey project from design till done of the whole project.

1.Project consultation

2.Design

3.Factory building

4.Installation

5.Commissioning

6.Training



Company Information

Jiayuan company was established in 1997, and for years we have been focusing on the improvement in machinery theory and performance in the food machinery industry. We have such as CE,ISO etc certification.
We are a company integrating scientific research, production and service, and have the best manufacturing facilities and production process, professional staffs, imported facilities of concentration distill series, automatic CIP series, PLC control etc. Now we have been a market leader in the Chinese food machinery industry. The company keeps in mind the tenet of "serving users" and focus on research and development of new technologies. It has comprehensive development capacity and sound quality assurance system, and has made R&D achievement and obtained invention patents. Our machinery are widely sold in China, and exported over 20 countries, and gained favorable feedback from users. Our major engineering projects include complete dairy products production line, beverage production line, biochemical engineering production line.
