Zhangjiagang Jiayuan Machinery CO., LTD
Professional liquid beverage filling and packing machinery manufacturer
 |
| Place of Origin: | Jiangsu, China (Mainland) |
| Brand Name: | Jiayuan |
| Certification: | CE SGS ISO |
| Model Number: | RCGF50-50-15 |
| Minimum Order Quantity: | 1 Set/Sets |
|---|---|
| Price: | US $15,000 - 1,000,000 / Set |
| Packaging Details: | Wooden Box |
| Delivery Time: | 30 Working Days |
| Supply Ability: | 15 Set/Sets per Month |
| Automatic Grade: | Automatic | Driven Type: | Electric |
|---|---|---|---|
| Voltage: | 380V/50HZ | Processing Types: | Water |
| Warranty: | One Year For Free | Power: | 9.63KW |
| High Light: | 24000BPH Rinsing Filling Capping Machine,Mineral Rinsing Filling Capping machine,SGS packaged drinking water filling machine |
||
Instruction
Details:
Capacity: 1,000-24,000 bottles per hour
Bottle Type: PET/PP/PE/HDPE Plastic Bottle
Bottle Shape: Round/Square/Rectangular/Irregular
Model: CGF 3 in 1 Monoblock
Place of Origin: Zhangjiagang city, China near Shanghai
Application: Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc
Bottle Type: 200ml to 2L
Cap Type: Screw cap, Pressing Cap, Sport cap
Full line including: Bottle Sorter, Rinser-Filler-Capper 3 in 1 machine, Lamp Checker, Labeling Machine, Film Shrink Machine/Carton Packing Machine
| Model | RCGF50-50-15 |
| Filling Material | Water,or juice |
| Bottle volume | 200-2000ml |
| Capacity | 24000BPH for 0.5L bottles |
| Washing heads quantity | 50 pieces |
| Filling heads quantity | 50 pieces |
| Capping heads quantity | 15 pieces |
| Filling temperature | Normal temperature or hot filling |
| Machine material | Stainless steel 304 |
| Power | 12kw |
| Weight | 1500kg |
| Dimension(L*W*H) | 7500*3900*2400mm |
Features:
1. Adopt the direct connection technology of air conveyor channel and bottle star-wheel, cancel the bottle screw and conveying chain, whcih makes changing bottle shape easily.
2. Bottle transmission adopts neck-hold technology. It is not necessary to adjust the height of the equipment to change the bottle shape.
3. The three-in-one unit to complete the bottle washing, filling, sealing three processes, bottle wear, accurate and stable transmission, convenient bottle replacement.
4. The specially designed stainless steel bottle punch is strong and durable. It does not touch the threaded part of the bottle mouth to avoid the secondary pollution of the bottle mouth.
5, High speed large flow gravity filling valve, filling speed is fast, the liquid level is accurate without liquid loss.
6. The parts and components in contact with the liquid are all made of high-quality stainless steel or food-grade engineering plastics. Most of the electrical systems are imported components, which meet the national food hygiene standards
7. The bottom plate of the rotary bottle adopts spiral descending mode, and the height of the conveying chain does not need to be adjusted when changing the bottle shape.
