6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    • 6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper
    • 6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper
    • 6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper
    • 6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper
  • 6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    Product Details:

    Place of Origin: China(mainland)
    Brand Name: JIAYUAN
    Certification: CE SGS
    Model Number: BCGF18-18-6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: pls inquiry
    Packaging Details: standard wooden cases
    Delivery Time: 35 working days
    Supply Ability: 99 sets per year
    Contact Now
    Detailed Product Description
    Product Name: Glass Bottle Beverage Filling Machine Function: Bottle Rising Filling Capping
    Model: BCGF18-18-6 Capacity: 6000B/H
    Suitable Bottle: Glass Bottle Suitable Cap: Crown Cap, Ring-pull Cap

    6000B/H Glass Bottle Non-Carbonated Soft Drinks/Juice Monoblock Filler And Capper

    Description

    This machine is for glass bottle non carbonated beverage production. It's specially customized for our demestic customer, which can seal two different kinds caps in one machine, crown cap and ring-pull cap. It adopt normal pressure filling, suitable for producing various juice, tea, water and other non-carbonated beverage. The rough capacity is about 5000-6000 bottles per hour.



    Parameter

    model BCGF18-18-6-6
    Suitble bottle Glass bottle
    Suitable cap Crown cap,ring-pull cap,aluminum screw cap
    Filling material Water, juice, tea, milk
    Fillingi type Normal pressure filling
    Rising/filling/capping heads number 18/18/6/6
    capacity 6000B/H(for 500ml)
    voltage 380V 50Hz or customized
    Material SUS304
    Dimension 2500*2000*2200mm
    weight 4000kg





































    Pictures

    rising

    6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    filling

    6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    crown cap sealing

    6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    ring-pull cap sealing

    6000B/H Capacity Glass Bottle Non-Carbonated Soft Drinks / Juice Monoblock Filler And Capper

    Our other products

    Model BCGF16-12-6 BCGF18-18-6 BCGF24-24-8 BCGF32-32-10 BCGF40-40-12 BCGF50-50-15
    Number of rising heads 16 18 24 32 40 50
    Number of filling heads 12 18 24 32 40 50
    Number of capping heads 6 6 8 10 12 15
    Bottle standard(mm)

    Diameter:Φ50-Φ108

    Height:150-320

    Rated production capacity(500ml) 4000BPH 6000BPH 10000BPH 12000BPH 16000BPH 24000BPH
    Installed capacity(KW) 3.8 4.3 6.5 8.7 9.5 12
