3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine

3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine

    • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
    • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
    • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
    • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
    • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine
  • 3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: Jiayuan
    Certification: CE SGS ISO
    Model Number: CGF9-9-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Price: US $15,000 - 1,000,000 / Set
    Packaging Details: Wooden Box
    Delivery Time: 30 Working Days
    Supply Ability: 15 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Machine Type: Filling Machine Packaging Material: Paper, Plastic, Wood
    Driven Type: Electric Power: 7kw
    Dimension(L*W*H): 3500mm*2500mm*2600mm Capacity: 1000b/h(5L)
    Weight: 3500kg



    5L Bottle Drinking / Mineral Water Washing Filling Capping Machine




    Description of 5L Drinking Water Washing Filling Capping Machine :



    5L Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.



    All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are



    from international famous brand.



    This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling



    plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling:



    gravity filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after



    filling and also control liquid level accurately. Capping: magnetic torque bottle holding type can minimize



    the cap damage rate and make the capping performance the best.



    This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size



    is the same, only the output star wheel needs to be changed if bottles are different. It improves the



    efficiency a lot.



    We are the water filling machine manufacturers in China.



    Technical parameter

    Machine name 5L bottled water production line mineral water processing machine / plant
    Model CGF9-9-4
    Filling speed 1000BPH(5L)
    When the plastic bottle change from 3L to 10L, there's no need to change any spare parts in the monoblock filling machine
    Rinsing head 9
    Filling head 9
    Capping head 4
    Dimension 3500mm*2500mm*2600mm
    Weight 4.5MT
    Power 7KW
    Control system Siemens PLC+touch screen
    Electrical element Schneider


    Overall apperance

    3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine

    Inside look

    3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine

    Touch screen

    3 In 1 Water Bottle Filling Machine , Industrial Drinking Water Plant Machine


    Customized service

    1. We can design the machines according your requirements (materil ,power,filling type,bottles, and so

    on),at the same time we will give you our professional suggestion,as you know,we have been in this

    industry for many years.

    2. We offer free technical support and consultation,such as draw the factory layout for you, alalyze the

    source water report and so on.


    If you want the detailed quotation including price,and the video of the machine or complet

    line,please kindly leave me the following information!!!!!!!

    1, bottle vlolume

    2, bottle materail (machines for glass bottle and plastic bottle are different)

    3, how many bottlesper hour you want to produce ?

    4, do you need this water filling machines only or whole water production line
