SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity

SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity

    • SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity
    • SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity
    • SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity
    • SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity
  • SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity

    Product Details:

    Place of Origin: China Mainland
    Brand Name: Jiayuan
    Certification: CE,SGS
    Model Number: BXGF12-12-4

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: 35000USD-95000USD
    Packaging Details: Seaworthy Wooden Case
    Delivery Time: 40 working days after down payment.
    Payment Terms: T/T; L/C
    Supply Ability: 20 sets/month
    Contact Now
    Detailed Product Description
    Application: Beverage Filling Material: SUS304
    Feature: Easy Operate Filling Material: Flowing Fluid
    Service: Top Service Model: CGF24-24-8



    CGF24-24-8 food stage SUS304 water bottling equipment with engineer oversea service






    Characteristic



    The suspending bottle-neck clamping design make the bottle stable during the high speed moving conditions. By changing a few parts, it can meet the need of different types of bottles easily.

    The new generation of stainless steel grab is adopted and the grabs have no contact with the arew above the bottle's screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.

    The advanced gravity filling technology used in this machine makes the filler quick,steady and accurate.

    Magnetic torque is used for screw capping,and the power of screw capping can be adjusted steplessly. Capping is reliable and do no harm to the caps.








    Model RCGF32-32-10
    Production capacity(500ml)(b/h) 14000
    Filling precision ≤±5MM(Liquid Level)
    Feedback consumption ≤10%
    Polyester bottle standard(mm) BottleDiameter)50-92;(Height):150-310
    Suitable cap shape (Plastic Screw Cap)
    Water pressure of washing bottle(Mpa) 0.18
    Wash pressure of washing bottle(kg/h) 3500
    Gas sourse pressure(Mpa) 0.6
    Gas consumption(m3/min 0.5
    Total power 9.18
    Total weight 5000
    Dimensions(L*W*H)(mm)

    3600×2800×315






    Main features:



    1. Bottles are delivered by suspension type clip bottle mouth conveying structure (except bottle out star wheel), bottle in adopts air conveying device, in the bottle washing station with flexible bottleneck clamp clamping, so that machine is more stable during operation , reliable, high-speed operation to adapt to the requirements of the machine.



    2. Dimidiate-type washing hand tongs, empty bottles with the guide rail automatically turn 180 º on to wash in and out of the bottles.



    3. Bottle Juice filling machine uses normal pressure filling technology is filling fast, reliable, non-drip, level accuracy. The machine has no bottle no filling characteristics.



    4. The bottle juice filling machine uses magnetic torque cover, to achieve grasping cover, screw caps, screw cap stepless torque, constant torque of the screw cap, without damage cover, seal tight and reliable.



    5. Cap arranging device ensure the cover arrange speed, no damage to the cover surface. Comprehensive testing device can guarantee no bottle no cover, lack of cover down, full cover without cover conveying of functions.



    6. The whole bottle juice filling machine adopts advanced man-machine interface operation, PLC control, variable frequency stepless speed regulation, such as automatic control technology, so that the whole of the high degree of automation, more reliable performance, production capacity can be adjusted continuously.



    Washing part of bottle washing filling capping machine

    a) Rotary pan is made of stainless steel 304.

    b) The rubber clamp splice seizes the mouth of bottles, which is fixedness and reliable.



    Filling part of bottle washing filling capping machine

    a) Rotary pan is made of stainless steel 304

    b) The way of filling is gravitation filling.

    c) The filling valve is adopted best stainless steel 304

    d) The structure of filling valve is reasonable, the amount is correct

    e) When filling the bottle, the bottle is move but the valve is stationary. The splint of bottle-neck seizes mouth of bottles. The elevator device with the action of gear realize the up and down of bottle



    Capping part of bottle washing filling capping machine

    Capping machine is one of the highest precision machines, which greatly affects the reliability of device and the defective rate of product. The characteristic is as follows:

    a) The dropping cap guide track fixes the device which can protect the cap from turning over and also set the device which can take out the inverse cap, equip a photo electricity switch which can

    stop the machine when lacking the cap and also avoid the situation that there is bottle without cap.

    b) The bottle inlet switch which is set in the capping machine, with the locking cap which is the connection of the dripping cap guide track and dialing cap pan controls the discharging of cap, making sure that stop conveyor cap when there is no bottles ,avoid the waste of cap.



    SUS304 Water Bottling Equipment With 14000 B / H High Production Capacity



    Service

    1.Installation

    After equipments reached the workshop of customer, place the equipments according to plane layout we offered. We will arrange seasoned technician for equipments installation, debug and test production at the same time make the equipments reach the rated producing capacity of the line. Time for installation and debug is 15-25 days.

    2.Training

    Our company offer technology training to customer. The content of training is structure and maintenance of equipments, control and operation of equipments. Training is in the workshop of customer. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

    3.Quality Guarantee

    We promise that our goods are all new and not used. They’re made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract. We promise that the products of this line could storage for one year without adding any aseptic.

    4.Aftersales

    If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.

    Offer wearing parts and other spare parts at favorable price; after quality guarantee, the technician of buyers should operate and maintain the equipments according to seller’s demand, debug some failures.
