Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine

Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine

    • Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine
    • Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine
    • Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine
    • Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine
  • Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine

    Product Details:

    Place of Origin: CHINA, MAINLAND
    Brand Name: jiayuan
    Certification: CE,SGS
    Model Number: DGCF

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Price: USD 22000 SET
    Packaging Details: WOODEN
    Delivery Time: 15WORK DAYS
    Payment Terms: T/T
    Supply Ability: 15 SETS PER MONTH
    Contact Now
    Detailed Product Description
    Condition: New Control: Touch Screen
    Color: Silvery White Volatge: 220v/380v
    Filling Volume: Adjustable Warranty: 1year Free
    Service: Oversea Service Driven Type: Electric
    High Light:

    Carbonated Soft Drink Filling Machine

    ,

    CSD Filling Machine



    silvery white 220v/380v carbonated filling line/automatic beer machine with mature technology





    Introduction



    The high-quality stainless machine is made and designed through introduce of technology from Germany KRONES Co., which has stained to the national top. It is mainly used for filling carbonated beverage with the method of holding the bottoms of the bottles. Adopting PLC control, automatic liquid level inspecting and hygienic structure, which is convenient to be operated and maintained.





    Features

    1. Multiple Usage: The filler provide a comprehensive range of different bottle sizes (height 150-320mm, Dia. 50-100mm)
    2. Easy adjustment: An automatic height adjust device is available which offers you very easy operation only by pressing a button. For filling different size of bottles, relative parts can be easily and quickly changed without tools.
    3. The filler carousel is mounted on a huge heavy duty combined bearing, which guarantees optimum smooth running of the filling bowl. The design of suspended and cantilevered bottle lift cylinders and bottle platforms allows easy, unrestricted remove of broken glass following bottle explosion which, with the addition of well protective of piston rods, minimizes the risk of damage of sliding surface of cylinders.
    4. High efficiency and low beverage loss: Owing to the special constructions features the machinery can run at high speed with low rate of glass broken. In the event of bottle breakage a burst flushing system can remove any fragments from the bottle platform, filling valve and centering bell assembly, filling valve automatically be closed in very short time avoiding beverage and gas loss.





    Technical parameters



    Item DCGF16-12-6 DCGF18-18-6 DCGF24-24-8 DCGF32-32-10
    Capacity 4000bph(500ml) 5000bph(500ml) 8000bph(500ml) 15000bph(500ml)
    Rising heads 16 18 24 32
    Filling heads 12 18 24 2
    Capping heads 6 6 8 10
    Bottle Diameter Commonly 50-110mm (can adjustable)
    Bottle Height Commonly 150-340mm(can adjustable)
    Filling pressure 0.15-0.35Mpa
    Rising pressure 0.2-0.25Mpa
    Overall size 2130*1700*2350 2450*1800*2350 2780*2200*2350 3600*2650*2350
    Weight 3.3t 3.5t 4.5t 5.5t



    Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine 0

    FAQ

    Automatic monoblock carbonated beverage filling machine

    Q1:Are you a trading company or a manufactory?

    A1:We are a manufactory,can give you best service .



    Q2:What’s your guarantee or the warranty of the quality if we buy your machines?

    A2:We offer you high quality machines with 1 years guarantee. We will give you spare part free in 1 years



    Q3:When can I get my machine after I paid?

    A3:We will deliver the machines on time as the date we agreed both side.



    Q4:How can I install my machine when it arrives?

    A4:We will send our engineer to your side as soon as you get all your machines ready, for testing and training your technicians how to run the machines.



    Q5:How about the spare parts?

    A5:After we deal down all the things, we will offer you a spare parts list for your reference



    Silvery White Carbonated Soft Drink Filling Machine Automatic Beer Machine 1
