Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
    • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
    • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
    • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
    • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
  • Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    Product Details:

    Place of Origin: Jiangsu, China (Mainland)
    Brand Name: Jiayuan
    Certification: CE ISO SGS
    Model Number: QS-12 DY-12 YG-6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Price: $6,000-20,000 / Set
    Packaging Details: Plastic film wrapping,wooden boxes packaging
    Delivery Time: 30 working days
    Payment Terms: L/C, T/T
    Supply Ability: 15 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Capacity: 2000 Bottles Per Hour Dimension(L*W*H): 1100*1050*1800mm
    Bottle Type: PET Plastic Glass Bottle Filling Material: Gas Liquid
    Function: Bottle Washing Filling Capping Color: Silver Gray
    Driven Type: Electric Voltage: 220V/380V
    Power: 1.1kw

    Split small scale isobaric filling beer/cola/carbonated



    water machine with glass bottle


    Specifications:
    Split small scale isobaric filling beer/cola/carbonated water machine with glass bottle
    1.Model:QS-12 DY-12 YG-6
    2.cola filling machine,beer filling machine,carbonated water filling machine

    3.small scale filling machine,isobaric filling machine
    4.glass bottle filling machine

    Introduction:
    Split small scale isobaric filling beer/cola/carbonated water machine with glass bottle
    QS-12 DY-12 YG-6 machine includes QS automatic washer,DY balanced pressure filler,FXZ cap turning machine,SSJ carrying machine ect.The key parts are made of stainless steel,with the features of reasonable stucture,advanced technology,easy in operation,widely used,etc,it's the ideal machine for middle and small beverage factory

    QS-12 Rotary Bottle Washer
    1.Adopt 1990s' technology of West Geramny SEN corp,also combining the condition of our country.
    2.It has high efficiency and good washing result by adopting continuously spraying and washing method.
    3.It is mainly used to clean the plastic glass bottles of beverage.
    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    DY-12 Balanced Pressure Filller
    1.The filler is developed on the basis of digesting and absorbing advanced technology introducing from abroad and with international advanced level.
    2.It is mainly usde for filling gas-containing drinks,such as aerated water,cola,sparkling wine,fruit tea and so on,It is advanced in construction,steadly in performance,safe in operation,easy in maintenance high in production effciency,and the speed can be regulated infinitively.
    3.The filler is the ideal choice for drink factories of small and middle type.
    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    YG-6 Automatic Capper
    The capper is the automatic capping and sealing equipment for bottled aerated water,sparkling wine,juice,health drink,soy sauce,vinegar and wine,production enterprises.
    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    Main technical parameter

    Model QS-12 DY-12 YG-6
    Production capacity 2000BPH
    Number of washing head 12
    Number of filling head 12
    Number of capping head 6
    Diameter of bottle 62-100mm
    Height of bottle 160-320mm
    Bottle volume 250,375,500,625ml
    Bottle/can type glass bottle,PVC bottle,POP-top can
    Filling pressure 0.2-0.3Mpa
    Filling temperature 2-6.C
    Cap type crown type
    Power 1.5kw


    Floating ball(used for liquid level testing)
    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    Washing part on-off controller
    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    Our workshop

    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity



    why choose us?

    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity

    1.One year warranty for the whole system.

    2.Free equipment installation and debugging.

    3.After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

    4.We can provide internship service and help you train the operator and mechanic.

    5.Free beverage production technology and process configuration.

    6.We can help you to design the product line, workshop and provide turn-key project.



    Packing&Shipping

    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity



    Payment

    30% deposit against the contract by T/T should be paid before the order;

    70% balance should be paid off by T/T after inspection before delivery;

    Delivery time

    30 days after received the down payment;

    Training

    Against the requests of the Buyer, the Seller’s technician could train the Buyer’s operators in the Buyer’s factory in the periods of installing & adjusting;



    Company Information

    Split Isobaric Cola / Carbonated Water Filling Machine Large Capacity
    Jiayuan company was established in1997,and for years we have been focusing on the improvement in machinery theory and performance in the food machinery industry.we have such as CE,ISO etc certification.
    We can provide our customer with the machines as following:
    1.Water bottle filling machine/whole production line
    2.Juice filling machine/whole production line
    3.Carbonated drink filling machine/whole production line
    4.Small scale beverage filling machine/production line(Such as water,juice,soda water,cola,beer...)
    5.1-5 gallon water barrel filling machine/production line
    6.Glass bottle filling machine
    7.Can filling machine
    8.Water treatment system/water purifying machines

    If you're satisfied with our machines,and want to get the detailed informations,please leave the information of your bottle size,your capacity,then contact me by following ways:
